Products introduction

Introduction of swing die standard parts

Shown above are some of the components of “Swing Die”.
For more details,please contact us.

　　　　　　
SD Trunnion Mount　　　　　　 Slide Block80(SB80)　　　　　　　 Swing Block A(SWBA)
One Handed Type(SDBSO)

　　　　　　　
Trunnion Mount Compact Type　　　　　　　 Swing Die Axle(SDAX)　　　　　　 Dwelling lower Plate(SDWL)
　　　　(SDBSO-XB)

　　 Half Mount B(HMSW-Ｂ)　　　　　　　 Half Mount Ａ(HMSW-A) SD Urethane Stopper(SDUS)

About custom-made products

When ordering non-standard dimensions other than the parts listed in our catalog, or custom-made products that require additional machining, please indicate "custom-made" at the end of the parts name and "-NS" at the end of the standard name.

Ex.When ordering 150‐wide custom-made product for slide block 80.
Parts name: Slide Block 80 custom-made Standard name: SB80M-150-NS

Delivery time⇒It depends on the parts, it will take about 4weeks after receiving the order before shipping.

Prohibition of illegal production of parts

Your Business Co.,Ltd. has registerd trademarks for "Swing Die" and "Swing Cam".
And we have obtained various patents for swing die mechanism, half-mount cam, related technologies & parts, and we are constantly developing new technologies & applying for patents in sequence.

Therefore, it is strictly prohibited to manufacture counterfeit products in-house or to have other company manufacture them without permission of Your Business Co.,Ltd.
